Mavlink ComPort: Selects the com port used for the MAVLink communication.Mavlink Gimbal: Enables the MAVLink Gimbal component and sets its component ID.In the dialog, accessible via the menu, one finds further relevant parameters, which are associated with the MAVLink Gimbal and MAVLink Camera components:

#GITUP GIT2 4K SERIAL#

Camera ComPort: Selects the UART port for camera models which use a serial interface.

This parameter is functional for all camera models, and not further discussed below. The time period is from the start of the first photo to the start of the second photo, and so on. If set to other than 0 photos will be taken continuously.

Camera Time Interval: Setting this to 0 (off) will result in one photo being taken.

The default is “video - off - shutter” (usually does not need to be changed).

Camera Control Mode: Functions executed then the primary input value is High or Low.

Camera Model: Selects the camera model.

Camera Control2: Selects a secondary input, which is used by some camera models.

Camera Control: Enables the function and selects the primary input.

The NT Camera is related to a number of parameters, which are located in two places in the GUI, the tab and the dialog.

8.3 CC3D NT IMU, STorM32 and Git2 Camera Integration.

2.2 Pin Assignment for the CC3D Atom and Atom Mini.

2.1 Pin Assignment on the v1.x and v2.x NT IMU Modules.

The subsequent introduction of the MAVLink Camera component and the serial API has brought unprecedented cool camera control features to the user. The NT Camera concept was introduced later, and extended to also provide PWM and serial UART signals to control cameras such as the Gitup Git2, RunCam Split, or GoPro Hero. Historically, the STorM32's remote camera control started with an IR LED controller on the v1.3x main STorM32 board, and several camera models which were supported by the STorM32, such as the Sony Nex, were related to this.

It will not be further discussed in this article however. This additional PWM signal can come in very handy and allows us doing all sorts of fancy things (e.g. That is, it outputs a servo PWM signal, which is an exact mirror of the PWM output signal available on the main STorM32 board, when the Pwm Out Control parameter is enabled. In addition, the NT Camera module also serves as a "PWM Out" module. For many camera models it is also possible to connect the camera, or a module operating it, directly to the STorM32 controller board, i.e., the STorM32 controller is then also a NT Camera module.

That is, the NT IMU module is also a NT Camera module (if it exposes the related pins to the user, which many of the available NT IMU modules do). Separate NT Camera modules have in fact not emerged, but the NT Camera function is integrated into the NT IMU firmware. It is thus usually connected to the NT bus near the camera NT IMU module, which results in extremely clean wiring schemes (see here). a servo PWM signal, the NT Camera module listens to the data on the NT bus. It thus serves a similar purpose as the various RC camera remote control modules, such as CAMremote, Seagull, Gentles, RcShutter, CamCntrl, IR Remote Shutter Controller, and all the other commercial and DIY solutions. The NT Camera module allows us to remote control a camera. The information on this page refers to firmware v2.61h and higher.
